Filter M8 waterproof connectors

M8 connectors can be described as a robust connectivity solution meeting the demands of modern industrial applications. M8 connectors, also known as M8 circular connectors, are available in various configurations, including the versatile M8 male connector and the corresponding M8 female connector.

Whether you’re in need of a 4-pin M8-A connector or a 3-pin M8-A connector, binder offers many variants of M8 connectors to suit your specific requirements. With options ranging from 5-pin M8 connectors to fieldbus connectors, our portfolio presents a comprehensive array of choices, all designed to excel in diverse industrial environments. Explore the possibilities of M8 connectors.

M8 circular connector Easy-to-mount M8 cable connectors to DIN EN 61076-2-104 in protection class IP65/67, unshielded and shielded versions with 360° shielding, iris spring and shielding rings ensure reliable EMC shielding. Rated current 1A to 4A and rated voltage 30V to 60V depending on the number of contacts. There are solder and screw terminals. The flange connectors have solder and dip solder connections or stranded wires. M8 cable assembly according to IEC 61076-2-104 has A code 3pins, 4pins, 6pins, 8pins and B code 5pins. The highest waterproof
grade is IP69K. Any length is available. Fremibs connectors always provide customized design to cover the whole requirement.

You can find your suitable M8 connectors from Fremibs.These connector systems offer the perfect solution for sensors and actuators in many branches of industry. We offer connectors from IP40 to IP69K, many with CE,RoHs,REACH and IP68 approval. Users can order circular connectors with 2 to 12 contacts and various termination options, including solder, crimp, dip solder, cable and stranded wire termination. Connectors with M5, M8 and M12 screw locking are available in straight and angled and flanged versions. In addition to duo connectors and dual distributors, a wide range of connecting cables is also available.

Features:

•2 to 8poles
• IP40 to IP69K
• Screw lock
• Easy installation
• RoHs, IP68,REACH and CEapproval
• Connecting lines
