M12 D-type 4-pin connectors, X-type 8-pin and A-type-8pin connectors are widely used in industrial Ethernet, Profinet, and EtherCAT due to their superior performance and reliability.
The M12 D-type 4-pin connector is primarily applied in industrial Ethernet communications, known for its excellent mechanical and environmental resistance. This connector is designed to maintain stable data transmission in harsh industrial environments, particularly suitable for automation and process control fields. They feature waterproof, dustproof, and anti-vibration characteristics, ensuring reliable operation under extreme conditions. Moreover, the standardized interface of the M12 D-type connector guarantees compatibility and interoperability between different devices and systems. The M12 X-type 8-pin connector, developed based on the IEC standard 61076-2-109, supports ultra-six-category 10Gbps high-speed Ethernet transmission. These connectors are widely used in industrial communications, industrial network wiring, video surveillance, and other areas requiring high-speed Ethernet transmission. M12 X-type connectors offer pre-molded cables, PCB panel mounts, and custom M12-RJ45 connection solutions, with cable materials and specifications that can be customized according to specific customer application needs. They use high-quality brass and phosphor bronze with gold-plated terminals, ensuring a lifespan of over 600 mating cycles. Additionally, these connectors boast excellent flexibility, wear resistance, and are UV-resistant, water-resistant, and oil-resistant, with a dynamic operating temperature range of -25 to 80°C and a static range of -40 to 80°C. The protection level reaches IP67, making them ideal for safe use in humid, submerged, and outdoor environments.
